Product Introduction
¡¡¡¡
This series of fan coils are independently developed by our company on the basis of combining superior features of other advanced products and designed and manufactured according to national standards. They are mainly designed for central air conditioning system and can be used to subsitute the traditional radiators that used in stores, hospitals, office buildings, and airports.
¡¡¡¡ Besides, ultra-thin models are alsow available for options. The series consists of 10 fundamental models: FP-3.5 (2.5), FP-5, FP-6.3, FP-7.1, FP-8, FP-10, FP-12.5, FP-14, FP-16, FP-20, with a ventilation capacity ranging from 350 to 2000m3/h and refrigerating capacity ranging from 2150W to 9750W. They can be classified, based on their forms, into ceiling built-in type, floor mount built-in type, ceiling hanging type, floor mount type. However, standard models and high static pressure models are also available.
Ceiling Built-in TypeCeiling Hanging TypeFloor Mount Type
Product Features

¡¡1. Outstanding quality and stable performance
¡¡¡¡ The surface coolers of fan coils are made of high quality copper tubes, aluminum foil and high strength galvanized steel sheets that are closely linked through tube deflation to achieve best heat transfer efficiency.

¡¡2. Stable running and low noise
¡¡¡¡ Thanks to the utilization of 3-speed motors and centrifugal wind wheels, the noise level is greatly reduced and the wind output capacity is increased. Thermal insulation and vibration reduction materials are used in every connection spot to create you a quite and comfortable space.

¡¡3. Advanced technique, safe and reliable in use
¡¡¡¡The company has a complete line of high automation equipment to produce fan coils of high quality and each coil produced is strictly tested to meet the requirement of high strength and impact resistance. Thus, the use safety can be relied.

¡¡4. 3-level speed regulation
¡¡¡¡The speed level can be adjusted at user's will to satisfy the needs for different wind volume.

¡¡5. Diversified types, easy to install
¡¡¡¡ The units are light and handy, only 23 cm thick. Ultra-thin type is only 20 cm thick. The water inlet and outlet tubes and the electric lines are easy to connect and the water flow directions and wind directions can be altered according to the site needs.¡¡Various installation types available to meet your decoration needs.

¡¡6. Complete selection of types
¡¡¡¡The coil range comes available in 10 types ranging from FP3.5 to FP20 for different air conditioned areas. Besides, ultra-thin coil is available for extremely small living space.


Illustration of Index Number



Featured Difference: S stands for "Standard Type"(default), G stands for "High Static Pressure"
Water Inlet: Z stands inlet on the left, Y stands for inlet on the right
Air Output: S stands for output from upper, Q stands for output from front
Air Return: X stands for return from bottom, H stands for return from back
Installation: M stands for surface installation, A stands for secret installation
Structure: L stands for vertical type, W stands for horizontal type
Nominal Air Volume: specified value X 100m3/h
Name of Product: fan coil
¡¡Taking FP-6.3WAH-(Q)Y for example, it indicates the product is a fan coil with a nominal air volume of 630m3/h, horizontal/secret installed, back air returned and front output, standard type.
Remarks:
1. The water inlet direction shall be on the opposite of air output direction.
2. If air return is unmarked, it means there is no air return box.
Technical Specifications of Blower Engine Coil

FP-3.5   FP-5   FP-6.3   FP-7.1   FP-8
air speed
high   mid   low   high   mid   low   high   mid   low   high   mid   low   high   mid   low
output m3/h
350   280   210   500   400   300   630   505   380   710   570   430   800   640   480
cooling capacity
kcal/h
1850   1610   1350   2600   2260   1900   3250   2830   2375   3690   2960   2690   4150   3610   3030
W
2158   1878   1575   3033   2637   2217   3792   3300   2770   4305   3453   3140   4842   4212   3535
heating capacity
kcal/h
3145   2550   2020   4415   3580   2845   5520   4485   3555   6220   5060   4020   7050   5720   4535
W
3669   2975   2357   5151   4177   3319   6440   5233   4148   7257   5903   4690   8225   6673   5291
maximum noise level dB(A)
36   28   24   38   30   26   39   34   31   41   38   32   43   38   32
water flow (kg/h)
370   520   650   720   830
water resistance (KPa)
0.38   0.75   1.34   1.75   2.12
maximum power (w)
45   58   70   78   85

   FP-10   FP-12.5   FP-14   FP-16   FP-20
air speed
high   mid   low   high   mid   low   high   mid   low   high   mid   low   high   mid   low
output m3/h
1000   800   600   1250   1000   750   1400   1120   840   1600   1280   960   2000   1600   1200
cooling capacity
kcal/h
4900   4265   3575   6000   5200   4380   6270   5820   4905   7750   6745   5660   9750   8485   7120
W
5717   4976   4171   7000   6067   5110   7315   6790   5723   9042   7869   6603   11375   9899   8307
heating capacity
kcal/h
9680   7855   6220   11855   9615   7620   13278   10770   8535   15310   12425   9855   19260   15630   12310
W
11293   9164   7257   13831   11218   8890   15491   12565   9958   17862   14496   11498   22470   18235   14362
maximum noise level dB(A)
44   39   33   45   33   23   46   33   26   48   37   25   52   44   31
water flow (kg/h)
980   1200   1330   1550   1950
water resistance (KPa)
3.29   0.98   1.06   1.56   2.7
maximum power (w)
83   132   138   145   190

Remarks:
¡¡1. 3-speed control for all models above;
¡¡2. capacity under air cooling condition: dry-bulb temp. 27¡æ, wet-bulb temp. 19.5¡æ, water enter temp. 7¡æ, feed water temp. 12¡æ;
¡¡3. capacity under air heating condition: dry-bulb temp. 21¡æ, water enter temp. 60¡æ;
¡¡4. environment noise below 20dB(A), testing spot 1m far from the unit;
¡¡5. coil pipes stand for the pressure test up to 3.0MPa, maximum working pressure allowed 1.68MPa;
¡¡6. 3-speed engine, input power source 200¡À10V(DC), 50¡À2.5Hz;
¡¡7. water input pipe:ZG3/4 female screw, water condensing pipe: ZG3/4 male screw

Instruction to Use:


Please note that all fan coils shall be installed, utilized and maintained by or under the instructions of professionals so as to avoid hurts or damages to operators and equipment.

1. Check before the installation whether the unit is kept in good condition and with complete components, whether the joints are fastened firmly. Wind wheel shall be strictly protected from striking or impact during the transportation.

2. The unit shall be installed accurately in horizontal direction so as the condensed water can be drained smoothly.

3. Please use soft pipes to connect unit and water supply system, and the copper joint shall be fastened solidly with spanner to protect the unit from possible damages.

4. All water pipes shall be wrapped with thermal insulation materials.

5. The power source used is single phase, 220¡À10V and 50¡À5HZ. Be noted that the phase wire shall be introduced into the motor from the beginning end and all joints shall be connected in maximum security to avoid potential dangers. Units in different types shall not share a same control switch.

6. The vent valve mounted above the joint of return pipes shall be opened before running and closed after the water tank is imbued.

7. The working temperature of unit is 600¡æ¡«650¡æ and the flow speed is 0.5¡«2.0m/s(suggested to select within the range of 0.5¡«1.0m/s)

8. The heat exchanger shall be cleaned from time to time to maintain a good heat transfer performance, and the filter net shall be cleaned regularly to keep a smooth air return.
